Pulsar Cable RAK9731/RAK9733
Notice: You can purchase longer Pulsar Cable RAK9733 for an additional price of 6USD per meter. Lead time would be 30 days. Please email us at inquiry@rakwireless.com with the following details:
- Pulsar Cable RAK9733 Length (should be in meter/m):
- Quantity:
- Company Name:
- Company VAT number (optional):
- Shipping Address:
- Billing Address:
- Contact Name:
- Contact number:
- Email Address:
- Courier Account details (optional):
| Frequency | 1.5-m / 4.9-f Length | 3-m / 9.8-f Length | 5-m / 16.40-f Length | 10-m / 32.80-f Length |
|---|---|---|---|---|
| 433 - 435 MHz | ≤ 0.30 dB | ≤ 0.15 dB | ≤ 0.65 dB | ≤ 1.15 dB |
| 470 - 510 MHz | ≤ 0.35 dB | ≤ 0.50 dB | ≤ 0.70 dB | ≤ 1.20 dB |
| 863 - 870 MHz | ≤ 0.10 dB | ≤ 0.63 dB | ≤ 0.85 dB | ≤ 1.65 dB |
| 902 - 930 MHz | ≤ 0.15 dB | ≤ 0.65 dB | ≤ 0.90 dB | ≤ 1.70 dB |
RAK9733
The Pulsar cable is a high-grade, low-loss cable, suitable for all gateways from the WisGate Developer series and the RAK Hotspot V2. This cable allows you to better position the gateway's antennas for optimal coverage.
Power Loss
| Frequency | 5-m / 16.40-f Length | 10-m / 32.80-f Length |
|---|---|---|
| 434 - 435 MHz | ≤ 0.65 dB | ≤ 1.15 dB |
| 471 - 510 MHz | ≤ 0.70 dB | ≤ 1.20 dB |
| 864 - 870 MHz | ≤ 0.85 dB | ≤ 1.65 dB |
| 903 - 930 MHz | ≤ 0.90 dB | ≤ 1.70 dB |
Product Features
- RAK9731
- Cable length variants: 1.5 m, 3 m, 5 m, 10 m
- Connector: N-type male to N-type female
- Frequency Range: 0~6 GHz
- Cable type: LMR400
- VSWR: ≤ 1.5
- RAK9733
- Cable length variants: 5 m, 10 m
- Connector: RP-SMA male to N-type female
- Frequency Range: 0~6 GHz
- Cable type: LMR400
- VSWR: ≤ 1.5
